CT FACIAL BONES/SINUSES CONTRAST

INDICATIONS (1-4)

facial bones con indications
  • Rhinosinusitis - acute, intracranial or orbital complication suspected (may need to including brain)

  • Sinonasal mass suspected

  • Sinusitis:
    - acute, rapid progression
    -  invasive fungal suspected

  • Dental abscess (consider inclusion of neck and mediastinum)

  • Soft tissue collection/infection

facial bones con pt prep

PATIENT PREPARATION

  • Patient able to lie still for ten minutes

  • Not claustrophobic (sedation may be given)

  • Cognitively capable of following basic instructions

  • Metal artefacts removed from the region of interest, including bra’s

  • No respiratory distress when lying supine

  • Not allergic to Iodine based Contrast

  • No known kidney disease (eGFR below 30 as per RANZCR), however, acute setting consultant may sign to continue with poor renal function

  • No hyperthyroidism, may induce thyroid storm

  • Patient to have 20G cannula in anterior cubital fossa.

  • Preferably patient fasted for 4 hours

facial bones con anatomy

ANATOMY INCLUDED


CT Facial Bones/Sinuses Contrast- Soft Tissue window (axial)
CT Facial Bones/Sinuses Contrast- Soft Tissue window (coronal)
CT Facial Bones/Sinuses Contrast- Soft Tissue window (sagittal)
CT Facial Bones/Sinuses Contrast- Bone window (axial)
CT Facial Bones/Sinuses Contrast- Bone window (coronal)
CT Facial Bones/Sinuses Contrast- Bone window (sagittal)

REFERENCES

​​

  1. Radiopaedia. CT Paranasal Sinuses (protocol). [Internet]. 2010 [updated 23 March 2023, cited 7 April 2024]. Available from https://radiopaedia.org/articles/ct-paranasal-sinus-protocol-1?lang=gb

  2. Som, P. M., & Curtin, H. D. (2011). Head and neck imaging. Mosby Elsevier.

  3. ACR–ASNR–SPR Practice parameter for the performance of computed tomography (CT) of the extracranial head and neck. American College of Radiology. (2023, August). https://www.acr.org/-/media/ACR/Files/Practice-Parameters/CT-Head-Neck.pdf

  4. American College of Radiology (ACR). Appropriateness Criteria. [Internet]. 2022 [Updated 2023, Cited 20 Jan 2024]. Available from https://www.acr.org/Clinical-Resources/ACR-Appropriateness-Criteria
